Revit Pure DIMENSIONS

  • Download
  • 5 files

Take a deep dive into Revit dimensions. In addition to learning everything about dimension types, you will learn how to automatically dimension elements by using Dynamo.
Buy now

Includes:

  • A 53 pages eBook PDF to help you master and automate dimensions.
  • 3 Dynamo scripts to auto-dimension walls and grids.
  • Revit dimension sample files, in Metric + Imperial, Revit 2021 to 2023.

Fun and Concise eBook PDF

This 53 pages PDF guide is made to be fun and efficient. After digging through dimension type and instance properties, you will learn Dynamo strategies to automate your dimensions.

Dynamo Scripts

The wall auto-dimension script will create dimensions to the interior or exterior extents of your wall:

The grids auto-dimension script will place dimensions to horizontal or vertical grids. Dimensions will always be placed on the top or left side. Grids that are not of equal length will be dimensioned separately.

Sample Dimension Files

The Revit sample file contain 111 dimension samples, each using different options and settings. Copy them directly to your template, or use them as inspiration to master and understand dimensions.

The sample files are available in both Metric + Imperial, in Revit 2021, 2022 and 2023.
.
